• Powerful, crank type mold clamping system combined with German linear guides for maximum stability.
  • This series is ideal for producing medium and large sized containers.
  • Multiple die head configuration is especially ideal for producing medium and small sized containers at high production speed. Custom machine configurations are available.
  • Also available to produce product with visi-stripe, two color and two layers.
  • 10” TFT colorful LCD screen with human-machine interface control system. It provides powerful functions, maximum operational convenience and user-friendly operation.


Model Max. Product Capacity Min./Max. Dia. Of Product Screw Dia. Outer Dia. Of Die Mouth Mould Center Distance
AV-PBS-905S 10000-20000cc 150-300mm 90mm 240mm -
AV-PBS-905D 1500-5000cc 80-180mm 90mm 135mm 250mm
AV-PBS-905T 600-2700cc 60-140mm 90mm 80mm 160mm
AV-PBS-905Q 450-1800cc 50-120mm 90mm 65mm 140mm
AV-PBS-905O 300-500cc 30-60mm 90mm 35mm 80mm
  • Specifications subject to change without notice.
