• Durable and horizontal traveling mold carriage combined with German linear motion guides for maximum stability.
  • The series is excellent for producing medium and large sized containers.
  • Available to equip with an auto deflashing device and take-out robot to achieve fully automatic and highly efficient production.
  • 10″ TFT colorful LCD screen with human-machine interface control system. It provides powerful functions, maximum operational convenience and user-friendly operation.


Model Max. Product Capacity Min./Max. Dia. Of Product Screw Dia. Outer Dia. Of Die Mouth Mould Center Distance
AV-PBS-605S 1000-5000cc 75-200mm 65mm 150mm -
AV-PBS-605D 450-1800cc 50-120mm 65mm 65mm 140mm
AV-PBS-605T 200-1000cc 30-100mm 65mm 50mm 120mm
AV-PBS-605Q 50-500cc 20-80mm 65mm 40mm 100mm
AV-PBS-705S 2500-10000cc 100-250mm 75mm 200mm -
AV-PBS-705D 600-2700cc 60-140mm 75mm 80mm 160mm
AV-PBS-705T 450-1800cc 50-120mm 75mm 65mm 140mm
AV-PBS-705Q 200-1000cc 30-100mm 75mm 50mm 120mm
  • Specifications subject to change without notice.
