• Custom design is available to suit various plastic materials such as PE, PP, PVC, PS, PC and nylon. Designated for producing medium and small sized containers.
  • Featuring fully flash-free and highly efficient automatic long production runs.
  • 5″ monochrome LCD screen combined with human-machine interface control system for user -friendly operations.


Model Product Capacity Product Dia. Screw Dia. Max. Die Mouth Dia. Mould Center Distance
AV-PBS-305S 50-500cc 20-80mm 40mm 40mm -
AV-PBS-305D 30-200cc 15-65mm 40mm 35mm 85mm
AV-PBS-305T 10-100cc 8-30mm 40mm 25mm 75mm
AV-PBS-405S 80-1000cc 30-100mm 45mm 55mm -
AV-PBS-405D 50-500cc 20-80mm 45mm 40mm 100mm
AV-PBS-405T 30-200cc 15-65mm 45mm 35mm 85mm
AV-PBS-405Q 10-100cc 8-30mm 45mm 25mm 75mm
AV-PBS-505S 450-2500cc 45-150mm 55mm 80mm -
AV-PBS-505D 200-1000cc 30-100mm 55mm 50mm 120mm
AV-PBS-505T 50-500cc 20-80mm 55mm 40mm 100mm
AV-PBS-405Q 30-200cc 16-65mm 55mm 35mm 85mm
  • Specifications subject to change without notice.
